System 5600 2" is available in depths from 5" to 7" along with a wide range of face cover depths. Tubular mullions are used vertically and horizontally for shear block construction. The slim 2" sightline is aesthetically pleasing while providing a hig performance system tested for a complete range of product applications.
- Acoustic Curtain Wall
- Improved sound reduction - STC rating of 30 or greater
- Thermal isolator used between exterior and interior extrusions
- Improved thermal performance
- Various mullion depths available
- Design flexibility
- Wide variety of snap-on face covers
- Customize projects with face covers of various depths and profiles
- Optional corner mullions
- Allows 90° and 135° inside and outside corners
- Shear block construction
- Ability to erect on the job site
- Integral door adaptors
- Compatible with all 1 3/4" EFCO doors
- Contact EFCO Product Technical Services for 2" Doors
- Accommodates up to 1 5/16" glazing
- Expands design and energy saving options
- Accessory line of perimeter anchors, pocket fillers, door adaptors, etc.
- Increased product versatility
- Anodized and painted finishes available
- Unlimited options to answer economic and aesthetic concerns
/5620c300.jpg)
Outside Glazed Offset Tongue
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
Outside Glazed Offset Tongue Door Frames
DetailsElevations
